Free Professional
Humidity Calculator

...as used in the national metrology institutions

  FROM   TO


- - -




gas temperature


gas pressure



      P A R A M E T E R S    S E T T I N G S





UNITS

  OTHER

temperature
pressure
density/abs.hum.
enthalpy
carrier gas
for other gases, specify molar mass
water vap. press. formulae

enhancement factor*

g/mol



The humidity calculator / moisture calculator accepts both dot or comma as a decimal symbol. A digit grouping symbol must be avoided.

Suggestions and errata are welcome to:

Terms and definitions


(Water) vapor pressure is the pressure exerted by a (water) vapor that is in equilibrium with its non-vapor phases. When the water vapor is in a mixture with a carrier gas (select it from the drop-down list in parameters settings), its vapor pressure can also be regarded as a partial pressure, having its stable maximum value at an equilibrium vapor pressure. The equilibrium vapor pressure (also referred to as a saturation vapor pressure), increases exponentially with the gas temperature according to relation, originally described by Clausius-Clapeyron equation. The humidity calculator / moisture calculator uses more accurate equations, which can be selected from the drop-down list in parameters settings.

In the presence of a carrier gas, the equilibrium vapor pressure for pure water is slightly increased by an enhancement factor, which depends upon the type of the carrier gas, the overall absolute gas pressure and the dew-point temperature. If checked, the humidity calculator / moisture calculator takes the enhancement factor into account for dry air and nitrogen. For other selected gases, the enhancement factor is disregarded. For gases other than those listed in the parameters settings, please provide also the molar mass.



Relative humidity is the ratio of the actual vapor pressure (equilibrium vapor pressure at dew point or frost point) to the equilibrium (saturation) vapor pressure at the gas temperature, expressed as a percentage. At gas temperatures below freezing, where possibility of super-cooling exists, the humidity calculator calculates relative humidity in either standard (%RH) or WMO (World Meteorological Organization) way. Since the super-cooling phenomenon does occur in clouds and the upper atmosphere, the WMO has decided that the relative humidity be calculated by computing the maximum possible water content over water rather than ice regardless of the temperature.

Dew point is the temperature at which dew, or condensation, forms, on cooling a gas. It is also the temperature, at which water vapor is in equilibrium with liquid water. The humidity calculator calculates the dew point from the inverse water vapor pressure formulae, selected by user.

Frost point is the temperature at which frost forms, on cooling a gas. It is also the temperature, at which water vapor is in equilibrium with ice. The humidity calculator calculates the frost point from the inverse water vapor pressure formulae, selected by user.

Parts per million by volume (PPMv) is the ratio of the water vapor volume to the volume of the dry carrier gas, multiplied by 106.

Parts per million by weight (PPMw) is the ratio of the water vapor mass to the mass of the dry carrier gas, multiplied by 106.

Wet-bulb temperature is the temperature indicated by a thermometer sheathed in a wet wicking, and influenced by a rate of evaporation from the wicking. The humidity calculator calculator finds the water vapor pressure e in the gas from the wet-bulb temperature tw , the gas temperature t, the gas pressure P and equilibrium vapor pressure e' at tw using the following equation:

e = e' - A.P.(t - tw).(1+B.tw)    ,

where A and B are the psychrometric constants, which can be set by user in the input boxes below.

A: C-1                       B: C-1


Absolute humidity is the mass of the water vapor present in unit volume of moist gas of a given temperature and pressure.

Specific humidity is the mass of water vapor per unit mass of moist gas.

Mixing (humidity) ratio is the mass of water vapor per unit mass of dry carrier gas with which it is associated.

Moist gas density is the mass of the moist gas in unit volume of moist gas of a given temperature and pressure.

Enthalpy is a measure of the total energy in a humid gas. Enthalpy of a gas can be defined as the sum of sensible and latent heat for each component in the gas. Values of enthalpy are conventionally expressed relative to a datum point (for a dry gas, this is normally the heat content at 0 C). The humidity calculator calculates the enthalpy for different carrier gasses and gas temperatures, based on the following constants (if left in auto mode, the calculator will use the mean value of cp  with respect to the gas temperature, except for SF6 , for which a manual input value shall be used):
  auto     manual
specific heat capacity of gas at constant pressure:     J/g/C
specific heat capacity of water at constant pressure:     J/g/C
evaporation heat of water at 0 C:     kJ/g





References
  • Hardy R., ITS-90 Formulations for Vapor Pressure, Frost point Temperature, Dew point Temperature, and Enhancement Factors in the range 100 to +100 C, Papers and Abstracts of the Third International Symposium on Humidity and Moisture, Vol. 1, pp. 214-222, April 1998
  • Sonntag D., Advancements in the field of hygrometry. (Review Article) Meteorologische Zeitschrift, N.F., 3, pp. 51-66, 1994
  • Wexler A., Vapor Pressure Formulation for Water in the Range 0 to 100C. A Revision, Journal of Research of the National Bureau of Standards, Physics and Chemistry, Vol. 80A, Nos. 5 and 6, pp. 775-785, 1976
  • Wexler A., Vapor Pressure Formulation for Ice, Journal of Research of the National Bureau of Standards
    A. Physics and Chemistry, Vol. 81A, No. 1, pp. 5-19, 1977
  • Buck Research Manual (1996); updated equation from Buck A. L., New equations for computing vapor pressure and enhancement factor, J. Appl. Meteorol., 20, pp. 1527-1532, 1981
  • Greenspan L., Functional Equations for the Enhancement Factors of CO2-Free Moist Air, Journal of Research of the National Bureau of Standards, Physics and Chemistry, Vol. 30A, No. 1, pp. 41-44, 1976
  • A Guide to the Measurement of Humidity, ISBN 0-904457-24-9, The Institute of Measurement and Control, London, 1996
  • tables for specific heat capacities at constant pressure - http://www.engineeringtoolbox.com/
